◆ Standard wavelengths: 808 nm, 830 nm, 850 nm, 905 nm, 940 nm, 1050 nm, 1150 nm, 1200 nm, 1300 nm, 1350 nm, 1450 nm, 1550 nm, 1650 nm, 1720 nm.
◆ Other wavelengths are customizable, with a customization range of 800–1700 nm.
◆ Optical power ranges from a minimum of 10 mW/cm² up to a maximum of 250 mW/cm².
◆ Length is customizable, flexible customization available from 100 mm to 5000 mm
| Model | Wavelenght | Length | Power |
|---|---|---|---|
| HS-BL-100-30-IR850 | 850nm | 100mm | 3W |
| HS-BL-100-30-IR940 | 940nm | 100mm | 3W |
| HS-BL-100-30-IR1050 | 1050n | 100mm | 2W |
| HS-BL-100-30-IR1150 | 1150nm | 100mm | 2W |
| HS-BL-100-30-IR1300 | 1300nm | 100mm | 2W |
| HS-BL-100-30-IR1450 | 1450nm | 100mm | 2W |
| HS-BL-100-30-IR1550 | 1550nm | 100mm | 2W |
| HS-BL-150-30-IR850 | 850nm | 150mm | 4.5W |
| HS-BL-150-30-IR940 | 940nm | 150mm | 4.5W |
| HS-BL-150-30-IR1050 | 1050nm | 150mm | 3.6W |
| HS-BL-150-30-IR1150 | 1150nm | 150mm | 3.6W |
| HS-BL-150-30-IR1300 | 1300nm | 150mm | 3.6W |
| HS-BL-150-30-IR1450 | 1450nm | 150mm | 3.6W |
| HS-BL-150-30-IR1550 | 1550nm | 150mm | 3.6W |
| HS-BL-200-30-IR850 | 850nm | 200mm | 6W |
| HS-BL-200-30-IR940 | 940nm | 200mm | 6W |
| HS-BL-200-30-IR1050 | 1050mm | 200mm | 4.5W |
| HS-BL-200-30-IR1150 | 1150nm | 200mm | 4.5W |
| HS-BL-200-30-IR1300 | 1300nm | 200mm | 4.5W |
| HS-BL-200-30-IR1450 | 1450nm | 200mm | 4.5W |
| HS-BL-200-30-IR1550 | 1550nm | 200mm | 4.5W |
| HS-BL-250-30-IR850 | 850nm | 250mm | 7.5W |
| HS-BL-250-30-IR940 | 940nm | 250mm | 7.5W |
| HS-BL-250-30-IR1050 | 1050nm | 250mm | 6W |
| HS-BL-250-30-IR1150 | 1150nm | 250mm | 6W |
| HS-BL-250-30-IR1300 | 1300nm | 250mm | 6W |
| HS-BL-250-30-IR1450 | 1450nm | 250mm | 6W |
| HS-BL-250-30-IR1550 | 1550nm | 250mm | 6W |
| HS-BL-300-30-IR850 | 850nm | 300mm | 9W |
| HS-BL-300-30-IR940 | 940nm | 300mm | 9W |
| HS-BL-300-30-IR1050 | 1050nm | 300mm | 7.5W |
| HS-BL-300-30-IR1150 | 1150nm | 300mm | 7.5W |
| HS-BL-300-30-IR1300 | 1300nm | 300mm | 7.5W |
| HS-BL-300-30-IR1450 | 1450nm | 300mm | 7.5W |
| HS-BL-300-30-IR1550 | 1550nm | 300mm | 7.5W |
| HS-BL-350-30-IR850 | 850nm | 350mm | 10.5W |
| HS-BL-350-30-IR940 | 940nm | 350mm | 10.5W |
| HS-BL-350-30-IR1050 | 1050nm | 350mm | 8.5W |
| HS-BL-350-30-IR1150 | 1150nm | 350mm | 8.5W |
| HS-BL-350-30-IR1300 | 1300nm | 350mm | 8.5W |
| HS-BL-350-30-IR1450 | 1450nm | 350mm | 8.5W |
| HS-BL-350-30-IR1550 | 1550nm | 350mm | 8.5W |
| HS-BL-400-30-IR850 | 850nm | 400mm | 12W |
| HS-BL-400-30-IR940 | 940nm | 400mm | 12W |
| HS-BL-400-30-IR1050 | 1050nm | 400mm | 9W |
| HS-BL-400-30-IR1150 | 1150nm | 400mm | 9W |
| HS-BL-400-30-IR1300 | 1300nm | 400mm | 9W |
| HS-BL-400-30-IR1450 | 1450nm | 400mm | 9W |
| HS-BL-400-30-IR1550 | 1550nm | 400mm | 9W |
| HS-BL-450-30-IR850 | 850nm | 450mm | 13.5W |
| HS-BL-450-30-IR940 | 940nm | 450mm | 13.5W |
| HS-BL-450-30-IR1050 | 1050nm | 450mm | 12W |
| HS-BL-450-30-IR1150 | 1150nm | 450mm | 12W |
| HS-BL-450-30-IR1300 | 1300nm | 450mm | 12W |
| HS-BL-450-30-IR1450 | 1450nm | 450mm | 12W |
| HS-BL-450-30-IR1550 | 1550nm | 450mm | 12W |
| HS-BL-500-30-IR850 | 850nm | 500mm | 15W |
| HS-BL-500-30-IR940 | 940nm | 500mm | 15W |
| HS-BL-500-30-IR1050 | 1050nm | 500mm | 12W |
| HS-BL-500-30-IR1150 | 1150nm | 500mm | 12W |
| HS-BL-500-30-IR1300 | 1300nm | 500mm | 12W |
| HS-BL-500-30-IR1450 | 1450nm | 500mm | 12W |
| HS-BL-500-30-IR1550 | 1550nm | 500mm | 12W |
